Pro Outdoor Series

Our outdoor LED display product line includes models P3, P3.07, P4.0, P5, P6, P8, and P10, available in two versions – Low Series and High Series – each with different specifications and performance levels to suit diverse needs

Lắp đặt 3D

Dải màu rộng

Độ sáng cao

Góc nhìn rộng

Hình ảnh sắc nét

Lắp đặt đa vị trí

Màu sắc rực rỡ

Tiết kiệm năng lượng

Product Description

HIGH BRIGHTNESS
Our outdoor LED products are designed with high brightness, ensuring clear and vivid display even under low-light conditions such as nighttime. The powerful brightness of the LED modules makes advertisements and presentation visuals stand out and remain visible at all times. This capability not only grabs the attention of passersby but also leaves a strong and lasting impression on the audience.

WIDE COLOR GAMUT
With a wide color gamut, our outdoor LED products deliver true-to-life and vibrant color reproduction. From primary colors to subtle shades, images and videos are rendered with exceptional color accuracy and brilliance, creating an immersive visual experience. This wide color spectrum enables greater creativity in displaying diverse and captivating content.

WIDE VIEWING ANGLE
Our outdoor LED modules are engineered with wide viewing angles, ensuring clear and detailed images from multiple perspectives. This expanded viewing angle enhances viewer convenience and elevates the overall visual experience. No matter where the viewer is standing, the visuals remain crisp and distortion-free.

SHARP IMAGE QUALITY
Thanks to high resolution and advanced display technology, our outdoor LED products reproduce visuals with outstanding clarity and precision. Every detail—from text to graphics—is displayed faithfully, providing a superior viewing experience. This sharpness significantly enhances the effectiveness of advertising and content delivery, attracting attention and leaving a memorable impression.

3D INSTALLATION
Beyond standard outdoor LED solutions, we also offer 3D outdoor LED installations. This allows for unique advertising and performance experiences with depth and motion effects. 3D LED technology unlocks boundless creativity, from lighting effects to dynamic animations, ensuring that your message captivates and engages like never before.

MULTI-LOCATION INSTALLATION
Our outdoor LED products are highly versatile and can be installed in various locations—on walls, poles, billboards, buildings, and more. This installation flexibility helps maximize space usage and advertising efficiency. You can make use of any available area to communicate your message effectively and attract attention wherever your display is set up.

VIVID COLORS
Our outdoor LED screens deliver vibrant and lively colors, creating visually stunning and impressive effects. Every detail on the screen is rendered with accuracy and brilliance, drawing attention from afar. The ability to reproduce subtle and precise colors ensures that every message and image is clearly conveyed and captivating.

ENERGY EFFICIENT
Thanks to energy-saving technology, our outdoor LED displays help reduce operating costs and support environmental sustainability. Power consumption is optimized without compromising display quality, ensuring efficient and cost-effective operation. This not only lowers your running expenses but also demonstrates our commitment to environmental protection and long-term durability.

PRO LOW SERIES – OUTDOOR LED DISPLAY – TECHNICAL SPECIFICATIONS

Specifications	PRO LOW P3.91 OUTDOOR	PRO LOW P4.81 OUTDOOR	PRO LOW P6.67 OUTDOOR
Pixel Pitch (mm)	3.91	4.81	6.67
Pixel Configuration	SMD 1921	SMD 1921	SMD 2727
Pixel Density (dot/m²)	65,536	43,264	22,500
Module Resolution	64 × 64	52 × 52	48 × 48
Module Size (mm)	250 × 250	250 × 250	320 × 320
Cabinet Resolution	128 × 128	104 × 104	96 × 96
Cabinet Size (mm)	500 × 500	500 × 500	640 × 640
Cabinet Material	Die-cast Aluminum	Die-cast Aluminum	Die-cast Aluminum
Cabinet Weight (kg)	7.5	7.5	12.5
Brightness (cd/m²)	≥ 4,500	≥ 4,500	≥ 5,000
Viewing Angle (H/V)	160° / 160°	160° / 160°	160° / 160°
Refresh Rate (Hz)	≥ 3,840	≥ 3,840	≥ 3,840
Contrast Ratio	5,000 : 1	5,000 : 1	5,000 : 1
Gray Scale (bit)	14 ~ 16	14 ~ 16	14 ~ 16
Input Voltage (V)	AC 100 ~ 240	AC 100 ~ 240	AC 100 ~ 240
Max Power Consumption (W/m²)	600	600	600
Avg Power Consumption (W/m²)	200	200	200
Protection Level (Front/Rear)	IP65 / IP54	IP65 / IP54	IP65 / IP54
Operating Temperature (°C)	-20 ~ +50	-20 ~ +50	-20 ~ +50
Lifespan (hours)	≥ 100,000	≥ 100,000	≥ 100,000
Control System	Novastar / Colorlight / Huidu / Linsn	Same	Same
Installation Type	Fixed or Rental	Fixed or Rental	Fixed or Rental

PRO HIGH SERIES – OUTDOOR LED DISPLAY – TECHNICAL SPECIFICATIONS

Specifications	PRO HIGH P2.97 OUTDOOR	PRO HIGH P3.91 OUTDOOR	PRO HIGH P4.81 OUTDOOR
Pixel Pitch (mm)	2.97	3.91	4.81
Pixel Configuration	SMD 1415	SMD 1921	SMD 1921
Pixel Density (dot/m²)	112,896	65,536	43,264
Module Resolution	84 × 84	64 × 64	52 × 52
Module Size (mm)	250 × 250	250 × 250	250 × 250
Cabinet Resolution	168 × 168	128 × 128	104 × 104
Cabinet Size (mm)	500 × 500	500 × 500	500 × 500
Cabinet Material	Die-cast Aluminum	Die-cast Aluminum	Die-cast Aluminum
Cabinet Weight (kg)	7.5	7.5	7.5
Brightness (cd/m²)	≥ 4,000	≥ 4,500	≥ 4,500
Viewing Angle (H/V)	160° / 160°	160° / 160°	160° / 160°
Refresh Rate (Hz)	≥ 3,840	≥ 3,840	≥ 3,840
Contrast Ratio	5,000 : 1	5,000 : 1	5,000 : 1
Gray Scale (bit)	14 ~ 16	14 ~ 16	14 ~ 16
Input Voltage (V)	AC 100 ~ 240	AC 100 ~ 240	AC 100 ~ 240
Max Power Consumption (W/m²)	650	650	650
Avg Power Consumption (W/m²)	220	220	220
Protection Level (Front/Rear)	IP65 / IP54	IP65 / IP54	IP65 / IP54
Operating Temperature (°C)	-20 ~ +50	-20 ~ +50	-20 ~ +50
Lifespan (hours)	≥ 100,000	≥ 100,000	≥ 100,000
Control System	Novastar / Colorlight / Huidu / Linsn	Same	Same
Installation Type	Fixed or Rental	Fixed or Rental	Fixed or Rental
